Bulge

A Magic Pocket with Everything You Need :)

Enhancement of Primitive Functions

Canvas

• Canvas Clean: Presentation Mode
• Canvas Clean +: Presentation Mode with Extra Clean Wire, Group, Panel
• Canvas Default: Default Grasshopper Canvas
• Canvas Custom: Customize All Canvas Elements

Params

• Number Slider +: Number Slider with Min, Max, Digit, Type Controls
• Button +: Button with Inverse Control
• MD Slider +: MD Slider with X, Y domain , Z Value Control
• Current File Path: Useful for locating file
• Current Folder Path: Useful for saving data stream

Maths

• Remap +: Remap with an Auto Input Range Detection
• Remap ++: Remap with Input Min, Input Max, Output Min, Output Max
• List Increment: {1, 2, 3, 5, 8} will output {1, 1, 2, 3}
• List Multiplier: {1, 2, 4, 8, 24} will output {2, 2, 2, 3}
• Mass Addition Until Value: with Different Termination Condition Options
• Mass Subtraction Until Value: with Different Termination Condition Options
• Mass Multiplication Until Value: with Different Termination Condition Options
• Mass Division Until Value: with Different Termination Condition Options
• Series +: Series allows multiple steps inputs

Sets

• Split List +: Split List Allowing Negative and Out-of-range Index Wrap
• Partition List +: Extra Options for Pattern
• Cull Nth +: Cull Nth Allowing Patterns with Multiple N Inputs
• First Last Tree Branch: Getting the First and the Last Branch from Tree
• First Rest Tree Branch: Getting the First and the Rest Branch from Tree
• Last Rest Tree Branch: Getting the Last and the Rest Branch from Tree
• First Last Tree Branch At Level: for example get first last branch within {0;1;*} sub-trees
• Split Tree at Index: Split the Tree with a Number Index, Similar to Renumber Tree and Then Split
• Path Mapper +: Path Mapper with text inputs

Vector

• Vector from Angle: Vector from a Plane and Degree. For a 2D 45 Degree Direction Just Feed 45
• Set Points: Set the x/y/z of points
• Set Points from Point: Match the x/y/z of points with a reference point

Curve

• Close Parallel Curves: E.g. Quickly Draw a Rectangle between 2 Parallel Lines, with Flip Option
• Circle Tan Tan Radius: All circles tangent to 2 reference curves with given radius
• Extend Curve Plus: Extend Curve with 0 as default inputs
• Sine Curve: Fast Sine curve from a start point and direction vector, using proxy points interpolation. Fast change peak, period, length...
• Sine Curve Simple: Fast Sine curve from a start point and direction vector, with much less control points. Perfect Nurb curve that mimic sine curve but less accurate. Fast change peak, period, length...
